Moldboard Plow
The moldboard plow is a fully suspended plow that is matched with a four-wheel tractor and is mainly suitable for plowing operations on sandy soil and dry land. This series of plow has the characteristics of simple adjustment, wide cultivation adaptability, good operation quality, and flat...
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
The moldboard plow is a fully suspended plow that is matched with a four-wheel tractor and is mainly suitable for plowing operations on sandy soil and dry land. This series of plow has the characteristics of simple adjustment, wide cultivation adaptability, good operation quality, and flat surface after cultivation.
|
Model |
1L-220 |
1L-320 |
1L-420 |
1L-520 |
1L-225 |
1L-325 |
1L-425 |
1L-525 |
|
Working Width (mm) |
400 |
600 |
800 |
1000 |
500 |
750 |
1000 |
1250 |
|
Working Depth (mm) |
200~250 |
|||||||
|
No.Of Bodies |
2 |
3 |
4 |
5 |
2 |
3 |
4 |
5 |
|
Total Weight (kg) |
64 |
100 |
130 |
170 |
125 |
170 |
240 |
270 |
|
Tractor power (hp) |
15~25 |
25~35 |
35~45 |
50~60 |
25 |
40 |
50 |
65 |
|
Linkage |
Three point mounted |
|||||||
|
Model |
1L-330 |
1L-430 |
1L-530 |
1L-335 |
1L-435 |
1L-535 |
|
Working Width (mm) |
900 |
1200 |
1500 |
1050 |
1400 |
1750 |
|
Working Depth (mm) |
220-270 |
|||||
|
No.Of Bodies |
3 |
4 |
5 |
3 |
4 |
5 |
|
Total Weight (kg) |
230 |
330 |
420 |
300 |
470 |
520 |
|
Tractor power (hp) |
50 |
70 |
80 |
55 |
75 |
90 |
|
Linkage |
Cat II |
|||||
